Alfa Laval ACVS808BD EMCSW
|
18358 |
| Marka |
Alfa Laval
|
| Typ |
ACVS808BD EMCSW
|
| Typ produktu |
Air Cooled Condenser
|
| Ogólna wydajność w kW |
900,0
|
| Liczba wentylatorów |
16
|
| Prdkość obrotów wentylatora (obr/min) |
880/860
|
| Czynnik chłodzący |
NH 3 (ammonia)
|
| Przepływ powietrza w m³/h |
345.200
|
| wentylatory o średnicy Ø |
800 mm
|
| Powierzchnia (m2) |
3094 m²
|
| Objętość rurki |
768,0 dm³
|
| Rozmiary |
11000x2300x2230 mm (LxWxH)
|
| Waga |
3508 kg
|
| Uwagi | |
Y.o.b. 2008
|
| Remarks || |
Capacity based on a condensation temperature of 35°C and a air temperature of 20/32°C (in/out).
|
| Liczba sztuk |
2 |
Alfa Laval ACVS808BD EMCSW
Used Alfa Laval ACVS808BD EMCSW air-cooled condenser. Complete with 16 Ziehl-Abegg FE080-SD6.6M fans - 50 Hz - 2,0/1,25 kW - 880/860 RPM - diameter 800 mm and a total airflow of 345.200 m³/h. Further the condenser comes with a control cabinet.
*All components of this used condensor will be tested on adequate functionality, leak free condition (electro engines), condensing block, bearings. Choosing HOSBV means buying with warranty. We perform an industrial cleaning. on demand, we can arrange your shipment.
